MI15KVe

MI15KVe

The MI-15KVe High-Voltage insulation tester is a truly portable device that allows the measurement of insulation resistances using test voltages up to 15kV.

It employs a state-of-the-art technology for the safe measurements of insulation resistances up to 3,000,000 MW with four test voltages: 1 kV - 5 kV - 10 kV and 15 kV.

Readings are performed through an easy-toread analogue indicator, having a broad scale.

Due to its reduced size and weight, its power autonomy and mechanical strength, this insulation tester is suitable for working out in the field, under severe weather conditions. It is powered with a rechargeable battery, with a charger for 110 V/220 V. In order to protect the equipment, the cabinet is water and dust resistant. Protection grade is IP54, and the insulation tester is supplied with a complete kit of high voltage test leads.

Features

  • Insulation test up to: 3 TΩ
  • 4 Test voltages: 1 kV - 5 kV - 10 kV - 15 kV
  • Guard terminal
  • Rechargeable battery
  • Multiple scales for precision improvement
  • IP-54 Protection

Specifications

Specifications
Test voltages 1 kV - 5 kV - 10 kV - 15 kV.
Maximum resistance reading

200 GΩ @ 1 kV.

1 TΩ @ 5 kV.

2 TΩ @ 10 kV.

3 TΩ @ 15 kV

Short circuit current 1 mA.
Test voltage accuracy ± 2% of nominal test voltages on R ≥ 10 GΩ.
Internal current limiting resistance

1 MΩ @ 1 kV.

5 MΩ @ 5 kV.

10 MΩ @ 10 kV.

15 MΩ @ 15 kV.

Insulation tester Accuracy Class 2 (±2 % of full scale deflection).
Analogue indicator Up to 98 mm scale length, taut band, with mirror.
